D-Link DES-1210-28P 24-Port PoE Smart Managed Switch

The D-Link DES-1210-28P is a 28-port Web Smart Managed PoE switch designed for IP surveillance, VoIP phones, wireless access points, and business networks. It provides 24 Fast Ethernet PoE ports, plus 4 Gigabit uplink ports, including 2 combo RJ45/SFP ports.

Key Features

• 24 × 10/100 Mbps PoE RJ45 ports
• 2 × 10/100/1000 Mbps Gigabit RJ45 ports
• 2 × Combo Gigabit RJ45/SFP ports
• 24 PoE ports
• IEEE 802.3af/at PoE+
• Ports 1–4: up to 30W per port
• Ports 5–24: up to 15.4W per port
• 193W total PoE budget
• 12.8 Gbps switching capacity
• 9.5 Mpps forwarding rate
• 8K MAC address table
• Store-and-forward switching
• VLAN support
• 802.1Q VLAN
• Voice VLAN
• QoS / 802.1p
• IGMP Snooping
• Link Aggregation / LACP
• STP / RSTP / MSTP
• Port Mirroring
• 802.1X authentication
• Access Control Lists
• DHCP Snooping
• IP-MAC-Port Binding
• Cable Diagnostics
• Web-based Smart Management
• SNMP support
• 19-inch rack-mountable
• Metal chassis

Ideal For

• CCTV / IP Camera Networks
• Wi-Fi Access Points
• VoIP Phones
• Offices & Businesses
• Hotels & Hospitality
• Schools & Campuses
• Retail Stores
• Warehouses
• Network Cabinets
• Small & Medium Enterprise Networks

The DES-1210-28P is particularly suitable for CCTV and access-point deployments, providing a 193W PoE budget and four Gigabit uplink interfaces while allowing centralized Layer 2 management.

Important: Despite being marketed as a 28-port switch, the 24 PoE access ports are only 10/100 Mbps. The Gigabit connectivity is provided by the 2 dedicated Gigabit RJ45 ports and 2 combo RJ45/SFP ports. D-Link currently lists this model as discontinued.
